Supplemental Information
• Embedded Options Available No
• DatasheetView now
• DescriptionDoes not include 3.5mm audio capabilities, Digital Microphones.
Memory & Storage
• Max Memory Size (dependent on memory type)64 GB
• Memory TypesDDR4-2666 1.2V SO-DIMM
• Max # of Memory Channels2
• Max Memory Bandwidth42.6 GB/s
• Max # of DIMMs2
• ECC Memory Supported ‡No
Processor Graphics
• Integrated Graphics ‡Yes
• Graphics OutputHDMI 2.0b; USB-C (DP1.2)
• # of Displays Supported ‡3
Expansion Options
• PCI Express RevisionGen3
• PCI Express Configurations ‡M.2 slot with PCIe X4 lanes
• Removable Memory Card SlotSDXC with UHS-II support
• M.2 Card Slot (storage)22×42/80
I/O Specifications
• # of USB Ports7
• USB Configuration2x front (Type-A, Type-C) and 3x rear USB 3.1 Gen2 (2x Type-A, Type-C); 2x USB 2.0 via internal headers
• USB Revision2.0, 3.1 Gen2
• USB 2.0 Configuration (External + Internal)0 + 2
• USB 3.0 Configuration (External + Internal)2B 2F + 0
• Total # of SATA Ports2
• Max # of SATA 6.0 Gb/s Ports2
• RAID Configuration2.5″ HDD/SSD + M.2 SATA SSD (RAID-0 RAID-1)
• Audio (back channel + front channel)7.1 digital (HDMI, Type-C)
• Integrated LANIntel® Ethernet Connection i219-V
• Integrated Wireless‡Intel® Wi-Fi 6 AX201
• Integrated BluetoothYes
• Consumer Infrared Rx SensorYes
• Additional HeadersCEC, 2x USB2.0, FRONT_PANEL, RGB
• # of Thunderbolt™ Ports1x Thunderbolt™ 3
